Illustration of the instrument
The illustration below shows the main parts of the instrument.
5
4
Part
1
2
3
4
ÄKTA start Maintenance Manual 29060308 AD
Description
Instrument Display
Wet side
Buffer tray
Power switch
3
1
2
Function
User interface for controlling the system and
visualization of the runtime data.
The modules interconnected by tubing have
the following functions:
to deliver the liquid in a specified flow path
•
and divert the flow as required,
to monitor the UV absorbance and
•
conductivity of the liquid.
Location intended for the placement of buffer
bottles used during chromatography runs.
Connects or disconnects the power.
