Package information

In order to meet environmental requirements, ST offers these devices in different grades of
ECOPACK
specifications, grade definitions and product status are available at: www.st.com.
ECOPACK
7.1

LQFP100, 14 x 14 mm, 100-pin low-profile quad flat package

information

Figure 29. LQFP100, 14 x 14 mm, 100-pin low-profile quad flat package outline

1. Drawing is not to scale.
Table 66. LQPF100, 14 x 14 mm, 100-pin low-profile quad flat package mechanical
Symbol
A
A1
A2
®
packages, depending on their level of environmental compliance. ECOPACK
®
is an ST trademark.
millimeters
Min Typ
-
0.050 -
1.350 1.400
DocID022881 Rev 10
data
Max
- 1.600
0.150
1.450
(1)
inches
Min Typ
- -
0.0020 -
0.0531 0.0551
®
Max
0.0630
0.0059
0.0571
