STM32L162VC, STM32L162RC
Pins
Pin name
A11 72 46 PA13
C11 73 - PH2
F11 74 47 V
SS_2
G11 75 48 V
DD_2
A10 76 49 PA14
A9 77 50 PA15
B11 78 51 PC10
C10 79 52 PC11
B10 80 53 PC12
C9 81 - PD0
B9 82 - PD1
C8 83 54 PD2
B8 84 - PD3
B7 85 - PD4
A6 86 - PD5
B6 87 - PD6
A5 88 - PD7
A8 89 55 PB3
Table 9. STM32L162xC pin definitions (continued)
Main
(3)
function
(after reset)
JTMS-
I/O FT
SWDIO
I/O FT PH2
S - V
SS_2
S - V
DD_2
JTCK-
I/O FT
SWCLK
I/O FT JTDI
I/O FT PC10
I/O FT PC11
I/O FT PC12
I/O FT PD0
I/O FT PD1
I/O FT PD2
I/O FT PD3
I/O FT PD4
I/O FT PD5
I/O FT PD6
I/O FT PD7
I/O FT JTDO
DocID022881 Rev 10
Pin functions
Alternate functions
JTMS-SWDIO
-
-
-
JTCK-SWCLK
TIM2_CH1_ETR/SPI1_NSS/
SPI3_NSS/I2S3_WS/
LCD_SEG17/JTDI
SPI3_SCK/I2S3_CK/
USART3_TX/LCD_SEG28/
LCD_SEG40/LCD_COM4
SPI3_MISO/USART3_RX/
LCD_SEG29/LCD_SEG4/
LCD_COM5/
SPI3_MOSI/I2S3_SD/
USART3_CK/LCD_SEG30/
LCD_SEG42/LCD_COM6
TIM9_CH1/SPI2_NSS/
I2S2_WS
SPI2_SCK/I2S2_CK
TIM3_ETR/LCD_SEG31/
LCD_SEG43/LCD_COM7
SPI2_MISO/USART2_CTS
SPI2_MOSI/I2S2_SD/
USART2_RTS
USART2_TX
USART2_RX
TIM9_CH2/USART2_CK
TIM2_CH2/SPI1_SCK/
SPI3_SCK/I2S3_CK/
LCD_SEG7/JTDO
Additional functions
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
COMP2_INM
39/123
46
