Ultra-low-power 32-bit MCU ARM-based Cortex
128KB Flash, 16KB SRAM, 4KB EEPROM, LCD, USB, ADC, DAC
Features
• Ultra-low-power platform
– 1.65 V to 3.6 V power supply
– -40°C to 85°C/105°C temperature range
– 0.3 µA Standby mode (3 wakeup pins)
– 0.9 µA Standby mode + RTC
– 0.57 µA Stop mode (16 wakeup lines)
– 1.2 µA Stop mode + RTC
– 9 µA Low-power Run mode
– 214 µA/MHz Run mode
– 10 nA ultra-low I/O leakage
– < 8 µs wakeup time
®
• Core: ARM
Cortex
– From 32 kHz up to 32 MHz max
– 1.25 DMIPS/MHz (Dhrystone 2.1)
– Memory protection unit
• Reset and supply management
– Ultra-safe, low-power BOR (brownout reset)
with 5 selectable thresholds
– Ultra-low-power POR/PDR
– Programmable voltage detector (PVD)
• Clock sources
– 1 to 24 MHz crystal oscillator
– 32 kHz oscillator for RTC with calibration
– High Speed Internal 16 MHz factory-trimmed
RC (+/- 1%)
– Internal Low Power 37 kHz RC
– Internal multispeed low-power 65 kHz to
4.2 MHz
– PLL for CPU clock and USB (48 MHz)
• Pre-programmed bootloader
– USART supported
• Development support
– Serial wire debug supported
– JTAG and trace supported
• Up to 83 fast I/Os (73 I/Os 5V tolerant), all
mappable on 16 external interrupt vectors
• Memories
– Up to 128 KB Flash with ECC
– Up to 16 KB RAM
– Up to 4 KB of true EEPROM with ECC
July 2014
This is information on a product in full production.
®
-M3 32-bit CPU
DocID17659 Rev 10
STM32L15xx6/8/B
BGA100 7 × 7 mm
LQFP100 14 × 14 mm
BGA64 5 × 5 mm
m
LQFP64 10 × 10
m
LQFP48 7 × 7 mm
– 80 Byte Backup Register
• LCD Driver for up to 8x40 segments
– Support contrast adjustment
– Support blinking mode
– Step-up converter on board
• Rich analog peripherals (down to 1.8 V)
– 12-bit ADC 1 Msps up to 24 channels
– 12-bit DAC 2 channels with output buffers
– 2x Ultra-low-power-comparators
(window mode and wake up capability)
• DMA controller 7x channels
• 8x peripherals communication interface
– 1x USB 2.0 (internal 48 MHz PLL)
– 3x USART (ISO 7816, IrDA)
– 2x SPI 16 Mbits/s
– 2x I2C (SMBus/PMBus)
• 10x timers: 6x 16-bit with up to 4 IC/OC/PWM
channels, 2x 16-bit basic timer, 2x watchdog
timers (independent and window)
• Up to 20 capacitive sensing channels
supporting touchkey, linear and rotary touch
sensors
• CRC calculation unit, 96-bit unique ID
Table 1. Device summary
Reference
STM32L151CB, STM32L151C8,
STM32L151C6, STM32L151RB,
STM32L151x6/8/B
STM32L151R8, STM32L151R6,
STM32L151VB, STM32L151V8
STM32L152CB, STM32L152C8,
STM32L152C6, STM32L152RB,
STM32L152x6/.8/B
STM32L152R8, STM32L152R6,
STM32L152VB, STM32L152V8
®
-M3,
-
Datasheet
production data
UFQFPN48
7 × 7 mm
Part number
www.st.com
1/129
