Table 8. Legend/abbreviations used in the pinout table

Abbreviation
Unless otherwise specified in brackets below the pin name, the pin function
during and after reset is the same as the actual pin name
S
I
I/O
FT
TC
B
RST
Unless otherwise specified by a note, all I/Os are set as floating inputs during
and after reset
Alternate
Functions selected through GPIOx_AFR registers
functions
Additional
Functions directly selected/enabled through peripheral registers
functions

Table 9. STM32L162xC pin definitions

Main
function
(after reset)
I/O FT PE2
I/O FT PE3
I/O FT PE4
I/O FT PE5
I/O FT PE6
(4)
S - V
LCD
I/O FT PC13
DocID022881 Rev 10
Bidirectional reset pin with embedded weak pull-up resistor
(3)
Alternate functions
TIM3_ETR/LCD_SEG38/
TRACECLK
TIM3_CH1/LCD_SEG39/
TRACED0
TIM3_CH2/TRACED1
TIM9_CH1/TRACED2
TIM9_CH2/TRACED3
-
-
Definition
Supply pin
Input only pin
Input / output pin
5 V tolerant I/O
Standard 3.3 V I/O
Dedicated BOOT0 pin
Pin functions
Additional functions
WKUP3/ RTC_TAMP3
WKUP2/RTC_TAMP1/
RTC_TS/RTC_OUT
-
-
-
-
-
