Package information
Table 66. LQPF100, 14 x 14 mm, 100-pin low-profile quad flat package mechanical
Symbol
b
c
D
D1
D3
E
E1
E3
e
L
L1
k
ccc
1. Values in inches are converted from mm and rounded to 4 decimal digits.

Figure 30. LQFP100, 14 x 14 mm, 100-pin low-profile quad flat package

1. Dimensions are in millimeters.
106/123
data (continued)
millimeters
Min Typ
0.170 0.220
0.090 -
15.800 16.000
13.800 14.000
- 12.000
15.800 16.000
13.800 14.000
- 12.000
- 0.500
0.450 0.600
- 1.000
0.0° 3.5°
- -

recommended footprint

DocID022881 Rev 10
STM32L162VC, STM32L162RC
Max Min
0.270 0.0067
0.200 0.0035
16.200 0.6220
14.200 0.5433
- -
16.200 0.6220
14.200 0.5433
- -
- -
0.750 0.0177
- -
7.0° 0.0°
0.080 -
(1)
inches
Typ Max
0.0087 0.0106
- 0.0079
0.6299 0.6378
0.5512 0.5591
0.4724 -
0.6299 0.6378
0.5512 0.5591
0.4724 -
0.0197 -
0.0236 0.0295
0.0394 -
3.5° 7.0°
- 0.0031
