Figure 33. Lqfp64, 10 X 10 Mm, 64-Pin Low-Profile Quad Flat Package - STMicroelectronics STM32L162RC Manual

STM32L162VC, STM32L162RC
Table 67. LQFP64, 10 x 10 mm 64-pin low-profile quad flat package mechanical data
Symbol
E3
e
K
L
L1
ccc
1. Values in inches are converted from mm and rounded to 4 decimal digits.
1. Dimensions are in millimeters.
millimeters
Min Typ
- 7.500
- 0.500
0° 3.5°
0.450 0.600
- 1.000
-

Figure 33. LQFP64, 10 x 10 mm, 64-pin low-profile quad flat package

DocID022881 Rev 10
(continued)
Max
-
-
7°
0.750
-
- 0.080
recommended footprint
(1)
inches
Min Typ
- 0.2953
- 0.0197
0° 3.5°
0.0177 0.0236
- 0.0394
- -
Max
-
-
7°
0.0295
-
0.0031
