STM32L162VC, STM32L162RC
Pins
Pin name
M3 29 20 PA4
K4 30 21 PA5
L4 31 22 PA6
M4 32 23 PA7
K5 33 24 PC4
L5 34 25 PC5
M5 35 26 PB0
M6 36 27 PB1
L6 37 28 PB2
M7 38 - PE7
L7 39 - PE8
M8 40 - PE9
L8 41 - PE10
M9 42 - PE11
L9 43 - PE12
M10 44 - PE13
M11 45 - PE14
M12 46 - PE15
L10 47 29 PB10
L11 48 30 PB11
F12 49 31 V
SS_1
Table 9. STM32L162xC pin definitions (continued)
Main
(3)
function
(after reset)
I/O - PA4
I/O - PA5
I/O FT PA6
I/O FT PA7
I/O FT PC4
I/O FT PC5
I/O - PB0
I/O FT PB1
PB2/
I/O FT
BOOT1
I/O - PE7
I/O - PE8
I/O - PE9
I/O - PE10
I/O FT PE11
I/O FT PE12
I/O FT PE13
I/O FT PE14
I/O FT PE15
I/O FT PB10
I/O FT PB11
S - V
SS_1
DocID022881 Rev 10
Pin functions
Alternate functions
SPI1_NSS/SPI3_NSS/
I2S3_WS/USART2_CK/
TIM2_CH1_ETR/SPI1_SCK
TIM3_CH1/TIM10_CH1/
SPI1_MISO/LCD_SEG3
TIM3_CH2/TIM11_CH1/
SPI1_MOSI/LCD_SEG4
LCD_SEG22
LCD_SEG23
TIM3_CH3/LCD_SEG5
TIM3_CH4/LCD_SEG6
BOOT1
-
-
TIM2_CH1_ETR/TIM5_ETR
TIM2_CH2
TIM2_CH3
TIM2_CH4/SPI1_NSS
SPI1_SCK
SPI1_MISO
SPI1_MOSI
TIM2_CH3/I2C2_SCL/
USART3_TX/LCD_SEG10
TIM2_CH4/I2C2_SDA/
USART3_RX/LCD_SEG11
-
Additional functions
ADC_IN4/DAC_OUT1/
COMP1_INP
ADC_IN5/DAC_OUT2/
COMP1_INP
ADC_IN6/COMP1_INP/
OPAMP2_VINP
ADC_IN7/COMP1_INP/
OPAMP2_VINM
ADC_IN14/COMP1_INP
ADC_IN15/COMP1_INP
ADC_IN8/COMP1_INP/
OPAMP2_VOUT/
VREF_OUT
ADC_IN9/COMP1_INP/
VREF_OUT
ADC_IN0b
ADC_IN22/COMP1_INP
ADC_IN23/COMP1_INP
ADC_IN24/COMP1_INP
ADC_IN25/COMP1_INP
-
-
-
-
-
-
-
-
