Danfoss VLT FC 302 Operating Instructions Manual page 99

Programming
Par. No. # Parameter description
16-6* Inputs & Outputs
16-60 Digital input
16-61 Terminal 53 switch setting
16-62 Analog input 53
16-63 Terminal 54 switch setting
16-64 Analog input 54
16-65 Analog output 42 [mA]
16-66 Digital output [bin]
16-67 Freq. input #29 [Hz]
16-68 Freq. input #33 [Hz]
16-69 Pulse output #27 [Hz]
16-70 Pulse output #29 [Hz]
16-71 Relay output [bin]
16-72 Counter A
16-73 Counter B
16-74 Prec. stop counter
16-75 Analog in X30/11
16-76 Analog in X30/12
16-77 Analog out X30/8 [mA]
16-78 Analog out X45/1 [mA]
16-79 Analog out X45/3 [mA]
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1
16-84 Comm. option STW
16-85 FC port CTW 1
16-86 FC port REF 1
16-9* Diagnosis Readouts
16-90 Alarm word
16-91 Alarm word 2
16-92 Warning word
16-93 Warning word 2
16-94 Ext. status word
MG37A202
Operating Instructions
Default value 4-set-up
0 N/A All set-ups
[0] Current All set-ups
0.000 N/A All set-ups
[0] Current All set-ups
0.000 N/A All set-ups
0.000 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0.000 N/A All set-ups
0.000 N/A All set-ups
0.000 N/A All set-ups
0.000 N/A All set-ups
0.000 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
FC 302 Change Conver-
only during sion index
operation
FALSE 0
FALSE -
FALSE -3
FALSE -
FALSE -3
FALSE -3
FALSE 0
x FALSE 0
FALSE 0
FALSE 0
x FALSE 0
FALSE 0
TRUE 0
TRUE 0
TRUE 0
FALSE -3
FALSE -3
FALSE -3
FALSE -3
FALSE -3
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
Type
Uint16
Uint8
Int32
Uint8
Int32
Int16
Int16
Int32
Int32
Int32
6 6
Int32
Int16
Int32
Int32
Uint32
Int32
Int32
Int16
Int16
Int16
V2
N2
V2
V2
N2
Uint32
Uint32
Uint32
Uint32
Uint32
97
