Programming
6.3.24 35-** Sensor Input Option
Par. No. # Parameter description
35-0* Temp. Input Mode
35-00 Term. X48/4 temp. unit
35-01 Term. X48/4 input type
35-02 Term. X48/7 temp. unit
35-03 Term. X48/7 input type
35-04 Term. X48/10 temp. unit
35-05 Term. X48/10 input type
Temperature sensor alarm
35-06 function
6 6
35-1* Temp. Input X48/4
Term. X48/4 filter time
35-14 constant
35-15 Term. X48/4 temp. monitor
35-16 Term. X48/4 low temp. limit
35-17 Term. X48/4 high temp. limit
35-2* Temp. Input X48/7
Term. X48/7 filter time
35-24 constant
35-25 Term. X48/7 temp. monitor
35-26 Term. X48/7 low temp. limit
35-27 Term. X48/7 high temp. limit
35-3* Temp. Input X48/10
Term. X48/10 filter time
35-34 constant
35-35 Term. X48/10 temp. monitor
35-36 Term. X48/10 low temp. limit
35-37 Term. X48/10 high temp. limit
35-4* Analog Input X48/2
35-42 Term. X48/2 low current
35-43 Term. X48/2 high current
Term. X48/2 low ref./feedb.
35-44 value
Term. X48/2 high ref./feedb.
35-45 value
Term. X48/2 filter time
35-46 constant

6.4 Parameter Lists - Active Filter

6.4.1 Operation/Display 0-**
Par. No. # Parameter description
0-0* Basic Settings
0-01 Language
Operating state at power-up
0-04 (hand)
0-1* Set-up Operations
106
Operating Instructions
Default value 4-set-up
[60] °C All set-ups
[0] Not Connected All set-ups
[60] °C All set-ups
[0] Not Connected All set-ups
[60] °C All set-ups
[0] Not Connected All set-ups
[5] Stop and trip All set-ups
0.001 s All set-ups
[0] Disabled All set-ups
App.Dependent All set-ups
App.Dependent All set-ups
0.001 s All set-ups
[0] Disabled All set-ups
App.Dependent All set-ups
App.Dependent All set-ups
0.001 s All set-ups
[0] Disabled All set-ups
App.Dependent All set-ups
App.Dependent All set-ups
4.00 mA All set-ups
20.00 mA All set-ups
0.000 N/A All set-ups
100.000 N/A All set-ups
0.001 s All set-ups
Default value
[0] English
[1] Forced stop All set-ups
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
FC 302 Change
only during
operation
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
4-set-up FC 302 Change
only during
operation
1 set-up
Conver- Type
sion index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-3 Uint16
- Uint8
0 Int16
0 Int16
-3 Uint16
- Uint8
0 Int16
0 Int16
-3 Uint16
- Uint8
0 Int16
0 Int16
-5 Int16
-5 Int16
-3 Int32
-3 Int32
-3 Uint16
Conver- Type
sion index
TRUE - Uint8
TRUE - Uint8
MG37A202
