Programming
Par. No. # Parameter description
1-6* Load Depen. Setting
1-60 Low speed load compensation
1-61 High speed load compensation
1-62 Slip compensation
1-63 Slip compensation time constant
1-64 Resonance dampening
1-65 Resonance dampening time constant
1-66 Min. current at low speed
1-67 Load type
1-68 Minimum inertia
1-69 Maximum inertia
6 6
1-7* Start Adjustments
1-71 Start delay
1-72 Start function
1-73 Flying start
1-74 Start speed [RPM]
1-75 Start speed [Hz]
1-76 Start current
1-8* Stop Adjustments
1-80 Function at stop
1-81 Min speed for function at stop [RPM]
1-82 Min speed for function at stop [Hz]
1-83 Precise stop function
1-84 Precise stop counter value
1-85 Precise stop speed compensation delay
1-9* Motor Temperature
1-90 Motor thermal protection
1-91 Motor external fan
1-93 Thermistor resource
1-94 ATEX ETR cur.lim. speed reduction
1-95 KTY sensor type
1-96 KTY thermistor resource
1-97 KTY threshold level
1-98 ATEX ETR interpol. points freq.
1-99 ATEX ETR interpol points current
76
Operating Instructions
Default value
100 %
100 %
App.Dependent
App.Dependent
100 %
5 ms
100 %
[0] Passive load
App.Dependent
App.Dependent
0.0 s
[2] Coast/delay time
null
App.Dependent
App.Dependent
0.00 A
[0] Coast
App.Dependent
App.Dependent
[0] Precise ramp stop
100000 N/A
10 ms
[0] No protection
[0] No
[0] None
0.0%
[0] KTY Sensor 1
[0] None
80 °C
App.Dependent
App.Dependent
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups x FALSE
All set-ups x FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2 set-ups x TRUE
All set-ups x TRUE
All set-ups x TRUE
1 set-up x TRUE
1 set-up x TRUE
2 set-ups x TRUE
Conver- Type
sion
index
0 Int16
0 Int16
0 Int16
-2 Uint16
0 Uint16
-3 Uint8
0 Uint8
- Uint8
-4 Uint32
-4 Uint32
-1 Uint8
- Uint8
- Uint8
67 Uint16
-1 Uint16
-2 Uint32
- Uint8
67 Uint16
-1 Uint16
- Uint8
0 Uint32
-3 Uint8
- Uint8
- Uint16
- Uint8
-1 Uint16
- Uint8
- Uint8
100 Int16
-1 Int16
0 Int16
