3-11 Jog Speed [Hz]
Range:
0 Hz [0.0 - par.
*
4-14 Hz]
3-15 Reference Resource 1
Option:
6 6
[0] No function
[1] Analog input 53
*
[2] Analog input 54
[7] Frequency input
29
[8] Frequency input
33
[11] Local bus
reference
[20] Digital pot.meter
[21] Analog input
X30-11
[22] Analog input
X30-12
3-16 Reference Resource 2
Option:
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Frequency input
29
[8] Frequency input
33
[11] Local bus
reference
[20] Digital pot.meter
*
[21] Analog input
X30-11
60
Operating Instructions
Function:
The jog speed is a fixed output speed at
which the frequency converter is running
when the jog function is activated.
See also 3-80 Jog Ramp Time.
Function:
Select the reference input to be used for
the first reference signal.
parameter 3-15 Reference Resource 1,
parameter 3-16 Reference Resource 2 and
parameter 3-17 Reference Resource 3
define up to 3 different reference
signals. The sum of these reference
signals defines the actual reference.
(General Purpose I/O Option Module)
(General Purpose I/O Option Module)
Function:
Select the reference input to be used
for the second reference signal.
parameter 3-15 Reference Resource 1,
parameter 3-16 Reference Resource 2
and parameter 3-17 Reference Resource
3 define up to 3 different reference
signals. The sum of these reference
signals defines the actual reference.
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
3-16 Reference Resource 2
Option: Function:
[22] Analog input
X30-12
3-17 Reference Resource 3
Option: Function:
Select the reference input to be used
for the third reference signal.
parameter 3-15 Reference Resource 1,
parameter 3-16 Reference Resource 2
and parameter 3-17 Reference Resource
3 define up to 3 different reference
signals. The sum of these reference
signals defines the actual reference.
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Frequency input
29
[8] Frequency input
33
[11] Local bus
*
reference
[20] Digital pot.meter
[21] Analog input
X30-11
[22] Analog input
X30-12
5-00 Digital I/O Mode
Option: Function:
NOTICE
Once this parameter has been changed,
perform a power cycle to activate the
parameter.
Digital inputs and programmed digital outputs are
pre-programmable for operation either in PNP or NPN
systems.
PNP Action on positive directional pulses (↕). PNP systems
[0]
*
are pulled down to GND.
NPN Action on negative directional pulses (↕). NPN
[1]
systems are pulled up to +24 V, internally in the
frequency converter.
MG37A202
