Danfoss VLT FC 302 Operating Instructions Manual page 77

Programming
6.3.3 1-** Load/Motor
Par. No. # Parameter description
1-0* General Settings
1-00 Configuration mode
1-01 Motor control principle
1-02 Flux motor feedback source
1-03 Torque characteristics
1-04 Overload mode
1-05 Local mode configuration
1-06 Clockwise direction
1-1* Motor Selection
1-10 Motor construction
1-2* Motor Data
1-20 Motor power [kW]
1-21 Motor power [HP]
1-22 Motor voltage
1-23 Motor frequency
1-24 Motor current
1-25 Motor nominal speed
1-26 Motor cont. rated torque
1-28 Motor rotation check
1-29 Automatic motor adaptation (AMA)
1-3* Adv. Motor Data
1-30 Stator resistance (Rs)
1-31 Rotor resistance (Rr)
1-33 Stator leakage reactance (X1)
1-34 Rotor leakage reactance (X2)
1-35 Main reactance (Xh)
1-36 Iron loss resistance (Rfe)
1-37 d-axis inductance (Ld)
1-39 Motor poles
1-40 Back EMF at 1000 RPM
1-41 Motor angle offset
1-5* Load Indep. Setting
1-50 Motor magnetisation at zero speed
1-51 Min speed normal magnetising [RPM]
1-52 Min speed normal magnetising [Hz]
1-53 Model shift frequency
1-54 Voltage reduction in fieldweakening
1-55 U/f characteristic - U
1-56 U/f characteristic - F
1-58 Flystart test pulses current
1-59 Flystart test pulses frequency
MG37A202
Operating Instructions
Default value
null
null
[1] 24V encoder
[0] Constant torque
[0] High torque
[2] As mode par 1-00
[0] Normal
[0] Asynchron
App.Dependent
App.Dependent
App.Dependent
App.Dependent
App.Dependent
App.Dependent
App.Dependent
[0] Off
[0] Off
App.Dependent
App.Dependent
App.Dependent
App.Dependent
App.Dependent
App.Dependent
App.Dependent
App.Dependent
App.Dependent
0 N/A
100 %
App.Dependent
App.Dependent
App.Dependent
0 V
App.Dependent
App.Dependent
30 %
200 %
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups x TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups x FALSE
All set-ups FALSE
All set-ups x FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups x FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
Conver- Type
sion
index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
6 6
- Uint8
1 Uint32
-2 Uint32
0 Uint16
0 Uint16
-2 Uint32
67 Uint16
-1 Uint32
Uint8
- Uint8
-4 Uint32
-4 Uint32
-4 Uint32
-4 Uint32
-4 Uint32
-3 Uint32
-4 Int32
0 Uint8
0 Uint16
0 Int16
0 Uint16
67 Uint16
-1 Uint16
-1 Uint16
0 Uint8
-1 Uint16
-1 Uint16
0 Uint16
0 Uint16
75
