Danfoss VLT FC 302 Operating Instructions Manual page 85

Programming
6.3.8 6-** Analog In/Out
Par. No. # Parameter description
6-0* Analog I/O Mode
6-00 Live zero timeout time
6-01 Live zero timeout function
6-1* Analog Input 1
6-10 Terminal 53 low voltage
6-11 Terminal 53 high voltage
6-12 Terminal 53 low current
6-13 Terminal 53 high current
6-14 Terminal 53 low ref./feedb. value
6-15 Terminal 53 high ref./feedb. value
6-16 Terminal 53 filter time constant
6-2* Analog Input 2
6-20 Terminal 54 low voltage
6-21 Terminal 54 high voltage
6-22 Terminal 54 low current
6-23 Terminal 54 high current
6-24 Terminal 54 low ref./feedb. value
6-25 Terminal 54 high ref./feedb. value
6-26 Terminal 54 filter time constant
6-3* Analog Input 3
6-30 Terminal X30/11 low voltage
6-31 Terminal X30/11 high voltage
6-34 Term. X30/11 low ref./feedb. value
6-35 Term. X30/11 high ref./feedb. value
6-36 Term. X30/11 filter time constant
6-4* Analog Input 4
6-40 Terminal X30/12 low voltage
6-41 Terminal X30/12 high voltage
6-44 Term. X30/12 low ref./feedb. value
6-45 Term. X30/12 high ref./feedb. value
6-46 Term. X30/12 filter time constant
6-5* Analog Output 1
6-50 Terminal 42 output
6-51 Terminal 42 output min scale
6-52 Terminal 42 output max scale
6-53 Term 42 output bus ctrl
6-54 Terminal 42 output timeout preset
6-55 Analog output filter
6-6* Analog Output 2
6-60 Terminal X30/8 output
6-61 Terminal X30/8 min. scale
6-62 Terminal X30/8 max. scale
6-63 Terminal X30/8 bus control
6-64 Terminal X30/8 output timeout preset
6-7* Analog Output 3
MG37A202
Operating Instructions
Default value
10 s
[0] Off
0.07 V
10.00 V
0.14 mA
20.00 mA
0 ReferenceFeed-
backUnit
App.Dependent
0.001 s
0.07 V
10.00 V
0.14 mA
20.00 mA
0 ReferenceFeed-
backUnit
App.Dependent
0.001 s
0.07 V
10.00 V
0 ReferenceFeed-
backUnit
App.Dependent
0.001 s
0.07 V
10.00 V
0 ReferenceFeed-
backUnit
App.Dependent
0.001 s
null
0.00 %
100.00 %
0.00 %
0.00 %
[0] Off
null
0.00 %
100.00 %
0.00 %
0.00 %
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
Conver- Type
sion
index
0 Uint8
- Uint8
-2 Int16
-2 Int16
-5 Int16
-5 Int16
6
-3 Int32
-3 Int32
-3 Uint16
-2 Int16
-2 Int16
-5 Int16
-5 Int16
-3 Int32
-3 Int32
-3 Uint16
-2 Int16
-2 Int16
-3 Int32
-3 Int32
-3 Uint16
-2 Int16
-2 Int16
-3 Int32
-3 Int32
-3 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
83
6
