Programming
6.3.2 0-** Operation/Display
Par. No. # Parameter description
0-0* Basic Settings
0-01 Language
0-02 Motor speed unit
0-03 Regional settings
0-04 Operating state at power-up (hand)
0-09 Performance monitor
0-1* Set-up Operations
0-10 Active set-up
0-11 Edit set-up
6 6
0-12 This set-up linked to
0-13 Readout: Linked set-ups
0-14 Readout: Edit set-ups/channel
0-15 Readout: actual setup
0-2* LCP Display
0-20 Display Line 1.1 small
0-21 Display Line 1.2 small
0-22 Display Line 1.3 small
0-23 Display Line 2 large
0-24 Display Line 3 large
0-25 My personal menu
0-3* LCP Custom Readout
0-30 Unit for user-defined readout
0-31 Min value of user-defined readout
0-32 Max value of user-defined readout
0-37 Display text 1
0-38 Display text 2
0-39 Display text 3
0-4* LCP Keypad
0-40 [Hand on] key on LCP
0-41 [Off] key on LCP
0-42 [Auto on] key on LCP
0-43 [Reset] key on LCP
0-44 [Off/Reset] key on LCP
0-45 [Drive Bypass] key on LCP
0-5* Copy/Save
0-50 LCP copy
0-51 Set-up copy
0-6* Password
0-60 Main menu password
0-61 Access to main menu w/o password
0-65 Quick menu password
0-66 Access to quick menu w/o password
0-67 Bus password access
74
Operating Instructions
Default value
[0] English
[0] RPM
[0] International
[1] Forced stop, ref=old
0.0 %
[1] Set-up 1
[1] Set-up 1
[0] Not linked
0 N/A
0 N/A
0 N/A
1617
1614
1610
1613
1602
App.Dependent
[0] None
0.00 CustomReadoutUnit
100.00 CustomRea-
doutUnit
0 N/A
0 N/A
0 N/A
null
null
null
null
null
null
[0] No copy
[0] No copy
100 N/A
[0] Full access
200 N/A
[0] Full access
0 N/A
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
4-set-up FC 302 Change
only during
operation
1 set-up TRUE
2 set-ups FALSE
2 set-ups FALSE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
Conver- Type
sion
index
- Uint8
- Uint8
- Uint8
- Uint8
-1 Uint16
- Uint8
- Uint8
- Uint8
0 Uint16
0 Int32
0 Uint8
- Uint16
- Uint16
- Uint16
- Uint16
- Uint16
0 Uint16
- Uint8
-2 Int32
-2 Int32
0 VisStr[25]
0 VisStr[25]
0 VisStr[25]
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Int16
- Uint8
0 Int16
- Uint8
0 Uint16
MG37A202
