Programming
[73] Logic Rule 3
[74] Logic Rule 4
[75] Logic Rule 5
[80] SL Digital
Output A
[81] SL Digital
6 6
Output B
[82] SL Digital
Output C
[83] SL Digital
Output D
[84] SL Digital
Output E
[85] SL Digital
Output F
[120] Local
reference
active
66
Operating Instructions
See parameter group 13-4* Logic Rules. If
logic rule 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If
logic rule 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If
logic rule 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See 13-52 SL Controller Action. The output
goes high whenever the smart logic action
[38] Set dig. out. A high is executed. The
output goes low whenever the smart logic
action [32] Set dig. out. A low is executed.
See 13-52 SL Controller Action. The input
goes high whenever the smart logic action
[39] Set dig. out. A high is executed. The
input goes low whenever the smart logic
action [33] Set dig. out. A low is executed.
See 13-52 SL Controller Action. The input
goes high whenever the smart logic action
[40] Set dig. out. A high is executed. The
input goes low whenever the Smart Logic
Action [34] Set dig. out. A low is executed.
See 13-52 SL Controller Action. The input
goes high whenever the smart logic action
[41] Set dig. out. A high is executed. The
input goes low whenever the smart logic
action [35] Set dig. out. A low is executed.
See 13-52 SL Controller Action. The input
goes high whenever the smart logic action
[42] Set dig. out. A high is executed. The
input goes low whenever the smart logic
action [36] Set dig. out. A low is executed.
See 13-52 SL Controller Action. The input
goes high whenever the smart logic action
[43] Set dig. out. A high is executed. The
input goes low whenever the smart logic
action [37] Set dig. out. A low is executed.
Output is high when 3-13 Reference Site =
[2] Local or when 3-13 Reference Site = [0]
Linked to hand auto at the same time as
the LCP is in [Hand on] mode.
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
Reference site set
in 3-13 Reference
Site
Reference site:
Local
3-13 Reference
Site [2]
Reference site:
Remote
3-13 Reference
Site [1]
Reference site:
Linked to Hand/
Auto
Hand
Hand ⇒ off
Auto ⇒ off
Auto
Table 6.8 Local and Remote Reference
[121] Remote Output is high when 3-13 Reference Site
reference =[1] Remote or [0] Linked to hand/auto
active while the LCP is in [Auto on] mode. See
Table 6.8.
[122] No alarm Output is high when no alarm is present.
[123] Start Output is high when there is an active
command start command (via digital input bus
active connection or [Hand on] or [Auto on]), and
no stop or start command is active.
[124] Running Output is high when the frequency
reverse converter is running counter clockwise
(the logical product of the status bits
'running' and 'reverse').
[125] Drive in hand Output is high when the frequency
mode converter is in [Hand on] mode (as
indicated by the LED light above [Hand
on]).
[126] Drive in auto Output is high when the frequency
mode converter is in [Hand on] mode (as
indicated by the LED light above [Auto
on]).
[151] ATEX ETR cur. Selectable if parameter 1-90 Motor Thermal
alarm Protection is set to [20] Above feedback
high or [21] Thermal warning. If the alarm
164 ATEX ETR cur.lim.alarm is active, the
output is 1.
[152] ATEX ETR freq. Selectable if parameter 1-90 Motor Thermal
alarm Protection is set to [20] Above feedback
high or [21] Thermal warning. If the alarm
166 ATEX ETR freq.lim.alarm is active, the
output is 1.
[153] ATEX ETR cur. Selectable ifparameter 1-90 Motor Thermal
warning Protection is set to [20] Above feedback
high or [21] Thermal warning. If the alarm
Local Remote
reference reference
active active [121]
[120]
1 0
0 1
1 0
1 0
0 0
0 1
MG37A202
