Danfoss VLT FC 302 Operating Instructions Manual page 94

Programming
6.3.15 14-** Special Functions
Par. No. # Parameter description
14-0* Inverter Switching
14-00 Switching pattern
14-01 Switching frequency
14-03 Overmodulation
14-04 PWM random
14-06 Dead time compensation
14-1* Mains On/Off
14-10 Mains failure
14-11 Mains voltage at mains fault
6 6
14-12 Function at mains imbalance
14-13 Mains failure step factor
14-14 Kin. backup time out
14-2* Trip Reset
14-20 Reset mode
14-21 Automatic restart time
14-22 Operation mode
14-23 Typecode setting
14-24 Trip delay at current limit
14-25 Trip delay at torque limit
14-26 Trip delay at inverter fault
14-28 Production settings
14-29 Service code
14-3* Current Limit Ctrl.
14-30 Current lim ctrl, proportional gain
14-31 Current lim ctrl, integration time
14-32 Current lim ctrl, filter time
14-35 Stall protection
14-4* Energy Optimising
14-40 VT level
14-41 AEO minimum magnetisation
14-42 Minimum AEO frequency
14-43 Motor cosphi
14-5* Environment
14-50 RFI filter
14-51 DC link compensation
14-52 Fan control
14-53 Fan monitor
14-55 Output filter
14-56 Capacitance output filter
14-57 Inductance output filter
14-59 Actual number of inverter units
92
Operating Instructions
Default value
null
null
[1] On
[0] Off
[1] On
[0] No function
App.Dependent
[0] Trip
1.0 N/A
60 s
[0] Manual reset
App.Dependent
[0] Normal operation
null
60 s
60 s
App.Dependent
[0] No action
0 N/A
100 %
0.020 s
1.0 ms
[1] Enabled
66 %
App.Dependent
10 Hz
App.Dependent
[1] On
[1] On
[0] Auto
[1] Warning
[0] No Filter
App.Dependent
App.Dependent
App.Dependent
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2 set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up x FALSE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
1 set-up x FALSE
Conver- Type
sion index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
- Uint8
-1 Uint8
0 Uint8
- Uint8
0 Uint16
- Uint8
- Uint8
0 Uint8
0 Uint8
0 Uint8
- Uint8
0 Int32
0 Uint16
-3 Uint16
-4 Uint16
- Uint8
0 Uint8
0 Uint8
0 Uint8
-2 Uint16
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-7 Uint16
-6 Uint16
0 Uint8
MG37A202
