Introduction
1
2 2
22
1 Local control panel (LCP)
2 Active filter card (AFC)
3 Metal oxide varistor (MOV)
4 Soft charge resistors
5 AC capacitors discharge board
6 Mains contactor
7 LC inductor
8 AC capacitors
9 Mains bus bars to drive input
10 IGBT fuses
11 RFI
Illustration 2.2 Frame Size D13 Filter Enclosure
6
Operating Instructions
2
3
21
20
19
18
16
15
14
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
4
5
17
13 Mains fuses
14 Mains disconnect
15 Mains terminals
16 Heat sink fan
17 DC capacitor bank
18 Current transformer
19 RFI differential mode filter
20 RFI common mode filter
21 HI inductor
22 Power card
6
7
8
9
10
11
12
13
