Danfoss VLT FC 302 Operating Instructions Manual page 107

Programming
6.3.23 34-** MCO Data Readouts
Par. No. # Parameter description
34-0* PCD Write Par.
34-01 PCD 1 write to MCO
34-02 PCD 2 write to MCO
34-03 PCD 3 write to MCO
34-04 PCD 4 write to MCO
34-05 PCD 5 write to MCO
34-06 PCD 6 write to MCO
34-07 PCD 7 write to MCO
34-08 PCD 8 write to MCO
34-09 PCD 9 write to MCO
34-10 PCD 10 write to MCO
34-2* PCD Read Par.
34-21 PCD 1 read from MCO
34-22 PCD 2 read from MCO
34-23 PCD 3 read from MCO
34-24 PCD 4 read from MCO
34-25 PCD 5 read from MCO
34-26 PCD 6 read from MCO
34-27 PCD 7 read from MCO
34-28 PCD 8 read from MCO
34-29 PCD 9 read from MCO
34-30 PCD 10 read from MCO
34-4* Inputs & Outputs
34-40 Digital inputs
34-41 Digital outputs
34-5* Process Data
34-50 Actual position
34-51 Commanded position
34-52 Actual Master position
34-53 Slave Index position
34-54 Master index position
34-55 Curve position
34-56 Track error
34-57 Synchronizing error
34-58 Actual velocity
34-59 Actual master velocity
34-60 Synchronizing status
34-61 Axis status
34-62 Program status
34-64 MCO 302 status
34-65 MCO 302 control
34-7* Diagnosis readouts
34-70 MCO alarm word 1
34-71 MCO alarm word 2
MG37A202
Operating Instructions
Default value 4-set-up
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
FC 302 Change Conver-
only during sion index
operation
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
FALSE 0
FALSE 0
Type
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
6 6
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Int32
Int32
Int32
Int32
Int32
Int32
Int32
Int32
Int32
Int32
Int32
Int32
Int32
Uint16
Uint16
Uint32
Uint32
105
