Danfoss VLT FC 302 Operating Instructions Manual page 143

Specifications
Normal Overload =110% current
for 60 s
Typical shaft output at 400 V [kW]
Typical shaft output at 460 V [hp]
Typical shaft output at 480 V [kW]
Enclosure IP21/54
Output current
Continuous (at 400 V) [A]
Intermittent (60 s overload) (at 400
V) [A]
Continuous (at 460/480 V) [A]
Intermittent (60 s overload) (at
460/480 V) [A]
Continuous kVA (at 400 V) [kVA]
Continuous kVA (at 460 V) [kVA]
Continuous kVA (at 480 V) [kVA]
Max. Input current
Continuous (at 400 V) [A]
Continuous (at 460/480 V) [A]
1)
Max. pre-fuses [A]
Max. cable size
2 2)
Motor (mm /AWG )
2 2)
Mains (mm /AWG )
Brake (mm 2 /AWG 2) )
Total LHD loss 400 V AC [kW]
Total back channel loss 400 V AC
[kW]
Total filter loss 400 V AC [kW]
Total LHD loss 460 V AC [kW]
Total back channel loss 460 V AC
[kW]
Total filter loss 460 V AC [kW]
Weight, enclosure IP21, IP54 [kg]
4)
Efficiency
Output frequency [Hz]
Heatsink overtemp. trip [°C]
Power card ambient trip [°C]
*Normal overload = 110% torque during 60 s
Table 11.3 Mains Supply 3x380-480 V AC
1) For type of fuse, see chapter 11.5.1 Fuses.
2) American wire gauge.
3) Measured using 5 m screened motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within ±15% (tolerence relates to
variety in voltage and cable conditions). Values are based on a typical motor efficiency (IE2/IE3 border line). Motors
with lower efficiency also add to the power loss in the frequency converter and opposite. If the switching
frequency is increased to the default setting, the power losses may rise significantly. LCP and typical control card
power consumptions are included. Further options and customer load may add up to 30 W to the losses. (Though
typical only 4 W extra for a fully loaded control card, or options for slot A or slot B, each).
Although measurements are made with state-of-the-art equipment, some measurement inaccuracy must be
allowed for (±5%).
MG37A202
Operating Instructions
P500 P560
NO NO
500 560
650 750
560 630
880 990
968 1089
780 890
858 979
610 686
621 709
675 771
857 964
759 867
1600
8 x 150 (8 x 300 mcm)
8 x 240 (8 x 500 mcm)
4 x 185 (4 x 350 mcm)
21909 24592
17767 19984
11747 12771
19896 22353
16131 18175
11020 11929
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
P630
NO
630
900
710
F18
1120
1232
1050
1155
776
837
909
1090
1022
2000
26640
21728
14128
25030
20428
13435
2009
0.96
0-600
105
85
P710
NO
710
1000
800
1260
1386
1160
1276
873
924
1005
1227
1129
30519
24936
15845
11 11
27989
22897
14776
141
