Programming
6.3.20 30-** Special Features
Par. No. # Parameter description
30-0* Wobbler
30-00 Wobble mode
30-01 Wobble delta frequency [Hz]
30-02 Wobble delta frequency [%]
Wobble delta freq. scaling
30-03 resource
30-04 Wobble jump frequency [Hz]
30-05 Wobble jump frequency [%]
30-06 Wobble jump time
6 6
30-07 Wobble sequence time
30-08 Wobble up/down time
30-09 Wobble random function
30-10 Wobble ratio
30-11 Wobble random ratio max.
30-12 Wobble random ratio min.
30-19 Wobble delta freq. scaled
30-2* Adv. Start Adjust
30-20 High starting torque time [s]
30-21 High starting torque current [%]
30-22 Locked rotor protection
30-23 Locked rotor detection time [s]
30-8* Compatibility (I)
30-80 d-axis inductance (Ld)
30-81 Brake resistor (ohm)
30-83 Speed PID proportional gain
30-84 Process PID proportional gain
100
Operating Instructions
Default value 4-set-up
[0] Abs. Freq., Abs. Time All set-ups
5.0 Hz All set-ups
25 % All set-ups
[0] No function All set-ups
0.0 Hz All set-ups
0 % All set-ups
App.Dependent All set-ups
10.0 s All set-ups
5.0 s All set-ups
[0] Off All set-ups
1.0 N/A All set-ups
10.0 N/A All set-ups
0.1 N/A All set-ups
0.0 Hz All set-ups
0.00 s All set-ups
100.0 % All set-ups
[0] Off All set-ups
0.10 s All set-ups
App.Dependent All set-ups
App.Dependent
App.Dependent All set-ups
0.100 N/A All set-ups
