Danfoss VLT FC 302 Operating Instructions Manual page 93

Programming
6.3.14 13-** Smart Logic
Par. No. # Parameter description
13-0* SLC Settings
13-00 SL controller mode
13-01 Start event
13-02 Stop event
13-03 Reset SLC
13-1* Comparators
13-10 Comparator operand
13-11 Comparator operator
13-12 Comparator value
13-1* RS Flip Flops
13-15 RS-FF operand S
13-16 RS-FF operand R
13-2* Timers
13-20 SL controller timer
13-4* Logic Rules
13-40 Logic rule boolean 1
13-41 Logic rule operator 1
13-42 Logic rule boolean 2
13-43 Logic rule operator 2
13-44 Logic rule boolean 3
13-5* States
13-51 SL controller event
13-52 SL controller action
MG37A202
Operating Instructions
Default value
null
null
null
[0] Do not reset SLC
null
null
App.Dependent
null
null
App.Dependent
null
null
null
null
null
null
null
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
4-set-up FC 302 Change
only during
operation
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
All set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
1 set-up TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
Conver- Type
sion
index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-3 Int32
6 6
- Uint8
- Uint8
-3 TimD
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
