Programming
6.3.18 17-** Motor Feedb.Option
Par. No. # Parameter description
17-1* Inc. Enc. Interface
17-10 Signal type
17-11 Resolution (PPR)
17-2* Abs. Enc. Interface
17-20 Protocol selection
17-21 Resolution (positions/rev)
17-24 SSI data length
17-25 Clock rate
17-26 SSI data format
6 6
17-34 HIPERFACE baudrate
17-5* Resolver Interface
17-50 Poles
17-51 Input voltage
17-52 Input frequency
17-53 Transformation ratio
17-56 Encoder sim. resolution
17-59 Resolver interface
17-6* Monitoring and App.
17-60 Feedback direction
17-61 Feedback signal monitoring
98
Operating Instructions
Default value
[1] RS422 (5V TTL)
1024 N/A
[0] None
App.Dependent
13 N/A
App.Dependent
[0] Gray code
[4] 9600
2 N/A
7.0 V
10.0 kHz
0.5 N/A
[0] Disabled
[0] Disabled
[0] Clockwise
[1] Warning
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
4-set-up FC 302 Change
only during
operation
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
Conver- Type
sion index
- Uint8
0 Uint16
- Uint8
0 Uint32
0 Uint8
3 Uint16
- Uint8
- Uint8
0 Uint8
-1 Uint8
2 Uint8
-1 Uint8
- Uint8
- Uint8
- Uint8
- Uint8
