Danfoss VLT FC 302 Operating Instructions Manual page 84

Programming
Par. No. # Parameter description
5-6* Pulse Output
5-60 Terminal 27 pulse output variable
5-62 Pulse output max freq #27
5-63 Terminal 29 pulse output variable
5-65 Pulse output max freq #29
5-66 Terminal X30/6 pulse output variable
5-68 Pulse output max freq #X30/6
5-7* 24V Encoder Input
5-70 Term 32/33 pulses per revolution
5-71 Term 32/33 encoder direction
5-8* I/O Options
6 6
5-80 AHF cap reconnect delay
5-9* Bus Controlled
5-90 Digital & relay bus control
5-93 Pulse out #27 bus control
5-94 Pulse out #27 timeout preset
5-95 Pulse Out #29 bus control
5-96 Pulse Out #29 timeout preset
5-97 Pulse Out #X30/6 bus control
5-98 Pulse Out #X30/6 timeout preset
82
Operating Instructions
Default value
null
App.Dependent
null
App.Dependent
null
App.Dependent
1024 N/A
[0] Clockwise
25s
0 N/A
0.00 %
0.00 %
0.00 %
0.00 %
0.00 %
0.00 %
Danfoss A/S © Rev. 2014-07-29 All rights reserved.
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
2 set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups x TRUE
1 set-up x TRUE
All set-ups TRUE
1 set-up TRUE
Conver- Type
sion
index
- Uint8
0 Uint32
- Uint8
0 Uint32
- Uint8
0 Uint32
0 Uint16
- Uint8
0 Uint16
0 Uint32
-2 N2
-2 Uint16
-2 N2
-2 Uint16
-2 N2
-2 Uint16
MG37A202
