Functionality Changes
Added Seamless Switching support, which can be enabled thru XGUI option. Refer to
Customizing and Generating the Core in Chapter 4
Instructions for Minimum Change Migration
SMPTE 2022-5/6 RX Migration from v3.0 to v4.0
Port Changes
In SMPTE 2022-5/6 RX v4.0, a new feature was added which supports SMPTE 2022-7, where
the receiver core receives two identical/seamless AXI-Streams (Primary and Secondary) with
different header as configured by the user. The port changes related to the new feature are
shown in Table
The secondary AXI-Stream Slave Interface and Ethernet Packets Received Interface signal is
visible only when Seamless Switching feature is enabled in the core setting. By disabling the
Seamless Switching, only primary AXI-Stream is visible and is similar to SMPTE 2022-5/6 RX
v3.0 core which uses single Ethernet Link.
*prefix pri_ is for Primary and sec_ for Secondary
*prefix N is indicating channel number
Table B-3: Port Changes as supporting SMPTE2022-7 Feature
SMPTE 2022-5/6 TX v3.0 Ports
s_axis_aresetn
s_axis_tdata[63:0]
s_axis_tkeep[7:0]
s_axis_tvalid
s_axis_tlast
s_axis_tready
rxN_rtp_pkt_recv
LogiCORE IP SMPTE 2022-5/6 RX v4.0
PG033 October 1, 2014
B-3.
www.xilinx.com
Appendix B: Migrating and Upgrading
for more information.
SMPTE 2022-5/6 TX v4.0 Ports
pri_s_axis_aresetn
sec_s_axis_aresetn
pri_s_axis_tdata[63:0]
sec_s_axis_tdata[63:0]
pri_s_axis_tkeep[7:0]
sec_s_axis_tkeep[7:0]
pri_s_axis_tvalid
sec_s_axis_tvalid
pri_s_axis_tlast
sec_s_axis_tlast
pri_s_axis_tready
sec_s_axis_tready
rxN_pri_rtp_pkt_recv
rxN_sec_rtp_pkt_recv
