5. Summing the each pool size,
AXI Memory Map Bandwidth Requirements
The memory bandwidth is calculated based on maximum input of 10Gbps per link to the
SMPTE 2022-5/6 RX including RTP and FEC packet regardless of Channel Number and SDI
Format.
The values on the table are based on worst case per port scenario.
Table 3-3: Receiver AXI-MM Port Bandwidth Consumption
M0_AXIMM WR
M0_AXIMM RD
M1_AXIMM WR
M1_AXIMM RD
Receiver Output Data Behavior
Figure 3-2 illustrates the receiver output data behavior.
LogiCORE IP SMPTE 2022-5/6 RX v4.0
PG033 October 1, 2014
Port
www.xilinx.com
Chapter 3: Designing with the Core
MaximumBandwidth (Gbps)
21.5
10.5
2.5
10.5
38
