Table 2-2: Resource Utilization for Virtex-7 FPGAs (xc7vx690t, Speed -1) (Cont'd)
SDI FEC
CHANNEL INCLUDE
7 0
8 0
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
Table 2-3: Resource Utilization for Kintex-7 FPGAs (xc7k325t, speed -1)
SDI FEC
CHANNEL INCLUDE
1 0
2 0
3 0
4 0
5 0
6 0
7 0
8 0
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
LogiCORE IP SMPTE 2022-5/6 RX v4.0
PG033 October 1, 2014
FFs LUTs Slices
24,876 14,492 9,012
27,743 15,233 8,710
12,900 9,248 4,109
16,398 11,506 5,364
20,042 13,649 6,973
23,656 14,892 8,093
27,284 16,976 10,833
30,893 19,142 11,032
34,491 20,451 13,137
38,105 21,571 13,310
FFs LUTs Slices
7,698 6,542 2,780
10,585 8,675 3,725
13,434 10,103 4,767
16,305 10,714 5,415
19,145 12,133 6,556
22,016 13,420 6,951
24,876 14,476 7,967
27,743 15,249 9,890
12,900 9,241 3,959
16,380 11,476 5,440
20,042 13,639 6,830
23,656 14,905 8,023
27,284 16,967 8,338
30,893 19,134 11,145
34,491 20,446 11,446
38,105 21,577 12,322
