Table 2-10: AXI4-Lite Register Map (Cont'd)
Address (Hex) Register Name
0x004C pri_discard_pkt_cnt
0x0050 sec_discard_pkt_cnt
0x0054 gen_stat_reset
0x0084 ip_hdr_param
0x0088 match_vlan
LogiCORE IP SMPTE 2022-5/6 RX v4.0
PG033 October 1, 2014
Default
Access Type
Value(HEX)
R 0x00000000
R 0x00000000
R/W 0x00000000
Channel
R 0x00000000
R/W 0x00000000
www.xilinx.com
Chapter 2: Product Specification
Description
Bit
Value
Range
Primary Discarded Packet Count
31:0 Number of not
matching pkts received
in the primary stream
Secondary Discarded Packet
Count
31:0 Number of not
matching pkts received
in the secondary
stream
General Statistics Reset
31:6 Reserved
5 Reset
sec_discarded_pkts_cnt
4 Reset
pri_discarded_pkts_cnt
3 Reset sec_err_pkts_cnt
2 Reset pri_err_pkts_cnt
1 Reset sec_recv_pkts_cnt
0 Reset pri_recv_pkts_cnt
IP Header Parameter
31:16 Reserved
15:8 type of service(TOS)
7:0 time to live(TTL)
Match VLAN
31 VLAN filtering
0 - Filter stream
without VLAN,
1 - Filter stream with
VLAN having tag info
in bit 15:0
30:16 Reserved
15:0 16-bit VLAN tag info
