HT2000LHF SETUP
Power supply interface cable
See Figure 3c-2.
Connect the interface cable plug to the 1X6 receptacle on the back of the power supply.
Connect the other plug of the interface cable to the CNC.
Install the 3 pairs of wires of the interface cable to the plasma interface assembly as shown
in Figure 3c-2.
See Figure 3c-3 for the interface cable part numbers and signal list.
3c-4
5
CommandTHC for X-Y Table Instruction Manual
