X-Y lifter assembly

• Mount the X-Y lifter assembly on the cutting table. See Figure 3-3.
22.4"
(570 mm)
3.5"
(89 mm)
3.5"
(89 mm)
3.5"
(89 mm)
2.875"
(73 mm)
THC.68
CommandTHC for X-Y Table Instruction Manual
1.41"
(36 mm)
4.5"
(114 mm)
5.0"
(127 mm)
Figure 3-3
1/4" (6 mm)
1.26"
(32 mm)
1.42"
2.12"
(36 mm)
(54 mm)
1.75"
(44.5 mm)
X-Y lifter assembly mounting
1/4-20
8.0"
(203 mm)
3.25"
(82.6 mm)
SETUP
2.8"
(71 mm)
3-5
