SPECIFICATIONS
Specifications
THC control module
Electrical
Input power (automatic selecting dual range) ..........115 VAC or 230 VAC, 1 phase,
Parallel digital I/O............................................................+ 12 VDC
Serial digital I/O (RS-422) ..........................................+ 5 VDC (operator pendant), CNC
14"
(355 mm)
5.6"
(142 mm)
(457 mm)
2-4
5
18"
Figure 2-2
50/60 Hz
THC control module
CommandTHC for X-Y Table Instruction Manual
24 lb
(11 kg)
