HT2000 SETUP
Electrode and work lead arc voltage wires
Turn off all electrical power before removing the power supply cover. Press the power
supply OFF (0) pushbutton switch and set the line disconnect switch to OFF. In the
U.S., use a "lock-out and tag-out" procedure until the service or maintenance is
complete. In other countries, follow appropriate local or national safety procedures.
See Figure 3b-1.
1. Remove access covers from the power supply, as required.
2. Locate the input/output panel on the back of the power supply.
3. Install the arc voltage wires:
Fabricate the wires as follows:
• Use 18AWG (≈0.9 mm
• Wire length: As required, from the power supply to the plasma interface assembly.
• After installing the wires from the power supply to the plasma interface assembly, install appropriate
size fork or ring terminals on the wire ends.
Connect one of the wires to the WORK LEAD (+) connection of the input/output panel. Label this wire
positive (+).
Connect the other wire to the NEGATIVE LEAD (–) connection of the input/output panel. Label this wire
negative (–).
At the plasma interface assembly, connect the negative (–) wire to the J5-2 terminal labeled
ELECTRODE. Connect the positive (+) wire to the J5-3 terminal labeled WORK.
