Power supply interface cable
See Figure 3g-3.
Connect the interface cable to the receptacle on the back of the power supply.
Install the 2 pairs of wires of the interface cable to the plasma interface assembly as shown in
Figure 3g-3.
See applicable Powermax service manual for the interface cable part numbers and signal list.
CommandTHC for X-Y Table Instruction Manual
POWERMAX SETUP
3g-5
