Motor Drive Cable - Hypertherm Command THC Instruction Manual

SETUP

Motor drive cable

To THC
control
module
Part number
123197
123198
123199
123200
123020
123201
123202
Pin
number Color
5 Output Red
4 Black
9 Output Red
8 Black
3
7 Output Red
6 Black
2 Output Red
1 Black
3-26
11
THC.83
Length
5 ft./1.5 m
10 ft./3 m
15 ft./4.6 m
20 ft./6.1 m
25 ft./7.6 m
30 ft./9.1 m
35 ft./10.6 m
Signal name
Motor Phase A +
Motor Phase A –
Motor Phase A +
Motor Phase A –
Motor Phase B +
Motor Phase B –
Motor Phase B +
Motor Phase B –
Figure 3-18 Motor drive cable – part numbers and signal list
Part number
123203
123204
123021
123205
123206
123207
123208
Function
Powers lifter motor, phase A+.
Powers lifter motor, phase A–.
Not connected
Powers lifter motor, phase B+.
Powers lifter motor, phase B–.
CommandTHC for X-Y Table Instruction Manual
To THC lifter
motor
Length
40 ft./12.2 m
45 ft./13.7 m
50 ft./15.2 m
75 ft./23 m
100 ft./30.5 m
125 ft./38 m
150 ft./45.6 m
Pin
number
5 Input
4
9 Input
8
3
7 Input
6
2 Input
1
