SETUP

Upon receipt

The THC system is shipped in two containers: one container holds the units; the other holds the cables. The containers
should include the following standard and optional components, if ordered:

Standard components

• THC control module
• 2 Power cords, 6.5 ft./2 m
• Plasma interface assembly
• X-Y lifter assembly
• Interface cables
– Lifter motor drive cable (9 pin)
– 3 Interface cables (37 pin)
– Ohmic contact wire
– Power supply interface cable (for Hypertherm power supplies only)
• Command X-Y THC system instruction manual

Optional components

• Operator pendant with 25 ft. (7.5 m) cable
• Pendant extension cable (9 pin)
• Torch mounting block kit
• Torch breakaway kit

Claims

Claims for damage during shipment — If your unit was damaged during shipment, you must file a claim with the
carrier. Hypertherm will furnish you with a copy of the bill of lading upon request. If you need additional assistance, call
Customer Service listed in the front of this manual, or your authorized Hypertherm distributor.
Claims for defective or missing merchandise — If any of the merchandise is defective or missing, call your
authorized Hypertherm distributor. If you need additional assistance, call Customer Service listed in the front of this
manual.

Power requirements

See THC control module in Section 2.
3-2
5
CommandTHC for X-Y Table Instruction Manual
