SETUP

Torch mounting block kit

• Mount the torch mounting block kit to the X-Y lifter assembly. See Figure 3-4. Refer to Section 6, Parts List for a
complete list of available kits and kit parts breakdowns.
Spacer
Hex screws (4)
Hex screws (2)
Block
Figure 3-4 X-Y lifter assembly torch mounting block
3-6 CommandTHC for X-Y Table Instruction Manual
