MAX200 SETUP
Power supply interface cable
See Figure 3f-2.
Connect the interface cable plug to the receptacle on the back of the power supply.
Install the 3 pairs of wires of the interface cable to the plasma interface assembly as shown in Figure 3f-2
See Figure 3f-3 for the interface cable part numbers and signal list.
3f-4
6
CommandTHC for X-Y Table Instruction Manual
