APPENDIX A – PARTS LIST FOR OLDER SYSTEMS

THC control module

Index no.
1
1
2
2
3
4
5
6
7
8
9
10
11
* These items can only be used with the older plasma interface assembly (128048). See previous page.
2
3
a-4
11
Part no. Description
053018 Control module
002261 Enclosure: control module
129067 Heatsink assembly
004705 Heatsink
005186 Power entry module: fused filter
008971 Fuse: T, 3.15 Amp, H 250 V, 5 mm x 20 mm
*041507 PCB: control (see figure on next page)
*081029
*081030
041511 PCB: motor drive (see figure on next page)
229070 Power source: 130W (see figure on next page)
123254 Cable: 50C ribbon (not shown)
129066 Wiring harness (not shown)
2
4
Control module exterior
Firmware: real-time microprocessor
Firmware: interface microprocessor
1
CommandTHC for X-Y Table Instruction Manual
Quantity
1
1
1
1
1
2
1
1
1
1
1
1
1
