HT4400 SETUP
Plasma interface PC board preparation
See Figure 3h-1.
Remove and discard the access cover from the plasma interface assembly.
Remove and discard the 2 connectors from the plasma interface PC board.
Remove the plasma interface PC board from the interface enclosure. Save the PC board, the
4 standoffs and the 4 mounting screws.
Discard the interface enclosure.
3h-2
5
CommandTHC for X-Y Table Instruction Manual
