OPERATION

THC Operating cycle time-lines

The following pages describe the normal operating cycle time-lines for the THC in the automatic and manual modes.
Table 4-1 lists the problems that can occur during a typical operating cycle in the automatic mode, as well as solutions
that can be done by the operator. The numbers shown in an operating cycle correspond to the numbers in the list of
problems and solutions.
The down force pressure of the X-Y THC Lifter has potential to cause injury. Be sure that the system is
in a safe condition before accessing the lifter area.
4-14
5
WARNING
THE THC LIFTER CAN INJURE YOUR HAND
CommandTHC for X-Y Table Instruction Manual
