APPENDIX B – PENDANT CONTRAST ADJUSTMENT PROCEDURE
2. Press F2 (AUTO/MAN button) until you get to the VIEWING ANGLE parameter.
3. Press F1 (MAINT/MODE button) to change the contrast setting until the display is easy to see.
4. Press F5 (IHS TEST/RUN button) to save the changes, and then press F1 (MAINT/MODE button) to acknowledge
that the change has been saved. The screen may "freeze" at this time, but will return to normal after about
15 seconds, or after a function key has been pressed.
Default pendant values
BAUD = 9600
DATA BITS = 8
PARITY = EVEN
ENABLE DISPLAY PE
REPEAT = SLOW
ENABLE KEY CLICK
DISABLE KNP FUNCTION
DISABLE CURSOR
DISABLE XON/XOFF
DISABLE HANDSHAKE
b-2
11
DISABLE ECHO
ESCAPE MODE = ANSI
CR/LF MODE = NORMAL
ENABLE TEST
DISABLE SHIFT LOCK
SCROLL ON LAST CHR
VIEWING ANGLE = 5
DISABLE BREAK CMND
SCREEN SIZE = 24 X 8
MENU MODE = DESTRUCTIVE
