the front of the chassis until the mounting bracket clip locks into place with an
audible click.
Verify that the rear locating pin has engaged the mounting bracket clip.
4.
Repeat
Step 2
5.
other side of the server.
6.
Attach slide rail assemblies to the rack.
See
"Attach Slide Rail Assemblies to the Rack" on page
Related Information
"Attach Slide Rail Assemblies to the Rack" on page 31
■
Attach Slide Rail Assemblies to the Rack
Use the rackmount installation card to identify the correct mounting holes for the slide rails.
Load the rack from bottom to top.
Note -
1.
Unpack the mounting brackets and installation card from the rackmount kit.
See
"Install the Rackmount Hardware" on page
2.
Ensure that there is enough vertical space in the cabinet to install the server.
See
"Rack Compatibility" on page
3.
Place the rackmount installation card against the front rails.
through
Step 4
to install the remaining mounting bracket on the
26.
Attach Slide Rail Assemblies to the Rack
31.
29.
Installing the Server
31
