Remove the Top Cover
Remove the Top Cover
All field-replaceable units (FRUs) that are not hot-swappable require the removal of the top
cover.
1.
Use a No. 2 Philips screwdriver and loosen the two green captive screws
securing the top cover on the rear of the server
FIGURE 2-1
Top Cover and Release Button
Slide the cover toward the rear of the server.
2.
3.
Lift the cover off the chassis and set it aside.
62
Sun Netra T5440 Server • September 2015
(Figure
2-1).
