Oracle Sun Netra T5440 Service Manual page 99

2. Disconnect all power cables from the server
3. Rotate the memory mezzanine green levers 90 degrees to vertical
Lift the memory mezzanine straight up and out of the chassis
4.
Place on an antistatic mat.
Removing the Memory Mezzanine
FIGURE 4-18
5. Remove the memory mezzanine riser cards.
6. Remove the riser cards by carefully pulling them straight up
Place on an antistatic mat.
Remove the Memory Mezzanine Assembly
(Figure 4-20).
Chapter 4 • Replacing Motherboard Assembly Components
(Figure 4-18).
(Figure 4-18).
(Figure 4-19).
99
