Install the Memory Mezzanine Assembly

Before You Begin
Note -
additional 16 FB-DIMM slots for a maximum of 32 FB-DIMM slots.
1. Install the memory mezzanine riser cards
Place them on the slot and carefully press until fully seated.
Installing the Memory Mezzanine Riser Cards
FIGURE 4-16
2. Place the memory mezzanine in the chassis.
Carefully set the memory mezzanine onto the riser cards
3.
Rotate the memory mezzanine green levers 90 degrees to horizontal
4.
4-17).
The memory mezzanine is an optional memory expansion assembly that provides an
Install the Memory Mezzanine Assembly
(Figure 4-16).
Chapter 4 • Replacing Motherboard Assembly Components
(Figure 4-17).
(Figure
