DIMM filler cards are required in all empty slots in the memory mezzanine tray.
Caution -
DIMM filler cards are not required on the motherboard.
32 slots hold industry-standard FB-DIMM memory modules. 16 slots are located on the
■
motherboard, and an additional 16 slots are available through a memory expansion upgrade
(memory mezzanine).
All FB-DIMMs must be the same density (same type).
■
Only single- and dual-rank fully buffered (FB) DIMMs, per JEDEC standard JESD206,
■
are supported.
FBDIMMs using x4 and x8 DRAMs are supported. However, chipkill is supported only
■
on x4-based FBDIMMs.All FBDIMMs within the system must be of the same total
capacity.
All FBDIMMs within the system must be of the same number of ranks.
■
All FBDIMMs within the system must use the same width (x4 or x8) DRAMs.
■
Mixing of FBDIMMs from different vendors is allowed.
■
Mixing of FBDIMMs with AMBs from different vendors is allowed.
■
There must b a minimum 8 FBDIMMs installed in the system.
■
At minimum, Channel 0, FB-DIMM Slot 0 in all branches must be populated with FB-
■
DIMMS of the same density (same type).
In branches populated with more than one FB-DIMM (for example, in 8 and 16 FB-DIMM
■
configurations), FB-DIMMs are addressed in pairs. Each pair must be identical (same part
number).
A replacement FB-DIMM must have the same part number as the other FB-DIMM in its
■
pair. For example, a replacement FB-DIMM in J1201 must have the same part number as
the FB-DIMM in J1401, in order to ensure an identical pair.
If you are unable to obtain a matching FB-DIMM, you must replace both FB‐ DIMMs in the
■
pair.
All Sun Netra T5440 servers support the following configurations, as shown in
8 FB-DIMMs (Group 1)
■
12 FB-DIMMs (Groups 1 and 2)
■
16 FB-DIMMs (Groups 1, 2, and 3) (fully populated motherboard)
■
4.7 FB-DIMM Configuration Reference
Chapter 4 • Replacing Motherboard Assembly Components
Figure 4-13:
