1
2
3
Note – If you need to remove a wire from the DC input plug, insert the cage clamp
operating tool or a small screwdriver into the slot directly above the wire and push
in. Pull the wire from the DC input plug.
9. Remove the cage clamp tool to secure the wire.
10. Repeat the procedures for the other two wires to complete the assembly of the
DC input power cable.
11. Repeat this procedure to create as many DC input power cables as you need for
your unit.
12. Prepare the power cords.
See
Related Information
"Prepare the Power Cords" on page 83
■
"Power On the Server for the First Time" on page 85
■
82 Netra SPARC T4-1 Server Installation Guide • January 2013
From -48V or -60V
From chassis ground (green/yellow)
From -48V or -60V Return
"Prepare the Power Cords" on page 83.
