No.
10
11
12
Related Information
"Rear Panel Components" on page 6
■
"Server Overview" on page 2
■

Rear Panel Components

No.
1
2
3
6 Netra SPARC T4-1 Server Installation Guide • January 2013
Description
Radio Frequency Identification (RFID)
tag
Fan modules (FM0 - FM4)
Hard drives (HDD0- HDD3)
Hard drive fan module (FM 5) (internal
- not shown)
Description
Power supplies (PS1 - PS0 top to
bottom) (AC supplies shown)
Power supply status LEDs:
- OK (output): (green)
- Service Action Required: (amber)
- AC or DC (input power): (green)
Alarm port
Link
Server Service, serving the fan modules
Server Service, serving the hard drives
Server Service, serving the hard drive fan
Link
"Prepare the Power Cords" on
page 83
"Assemble the DC Power Cords"
on page 80
Server Service, interpreting
diagnostic LEDs
"Alarm Port" on page 68
