Note – References to left and right are from your viewpoint as you face either the
front or rear of the equipment.
Caution – The server is heavy. Two people are required to lift and mount the server
into a rack enclosure when following these procedures.
Caution – You must install the server into a rack following these instructions. If you
deviate from these instructions when installing the server, your installation will not
be supported.
Description
Mount the server using a 19-inch,
4-post hardmount rackmount kit
(included with the server).
Mount the server using an optional
19-inch, 4-post slide rackmount kit
for 600–800 mm cabinet depths.
Mount the server using an optional
600 mm x 600 mm rackmount kit.
Related Information
"Preparing for Installation" on page 19
■
"Rack Cautions" on page 24
■
"Stabilize the Rack for Installation" on page 25
■
26 Netra SPARC T4-1 Server Installation Guide • January 2013
Links
"19-Inch, 4-Post Hardmount Rackmount Kit" on
page 27
"Install the Server (19-Inch, 4-Post Hardmount
Rackmount Kit)" on page 28
"19-Inch, 4-Post Sliding Rail Rackmount Kit" on
page 30
"Install the Server (19-Inch, 4-Post Sliding Rail
Rackmount Kit)" on page 32
"600-mm, 4-Post Hardmount Rackmount Kit" on
page 37
"Install the Server (600-mm, 4-Post Hardmount
Rackmount Kit)" on page 38
