Identifying Ports; Alarm Port - Sun Oracle NETRA SPARC T4-1 Installation Manual

Power cables to the power supply inlet ports
■
Related Information
"Electrical Specifications" on page 10
■
"Rear Panel Components" on page 6
■
"Identifying Ports" on page 68
■

Identifying Ports

These topics provide the pin descriptions of the ports. See
on page
"Alarm Port" on page 68
■
"SER MGT Port" on page 70
■
"NET MGT Port" on page 70
■
"Gigabit Ethernet Ports" on page 71
■
"USB Ports" on page 72
■
"Video Port" on page 73
■
Related Information
"Rear Panel Components" on page 6
■
"Cabling Requirements" on page 67
■

Alarm Port

The alarm port on the rear panel uses a standard DB-15 connector that provides a
connection for a Telco dry alarm relay cable. In a telecommunications environment,
use this port to connect to the central office alarming system. The alarm port relay
contacts are rated for 100V, 0.2A maximum.
68 Netra SPARC T4-1 Server Installation Guide • January 2013
6.
"Rear Panel Components"
